High Reliability LCC Sockets
Only Available From Andon Electronics Corporation
Unique Design Avoids Cracking of Solder Joints and Ceramic Substrate:
- LCC Image Sensors are packaged with up to 100 castellations (contacts).
- The ceramic substrate packaging presents new challenges for RoHS high temperature soldering.
Eliminating the Cracking of LCC Substrate and Solder Joints:
- Historically, Image Sensors are soldered directly on the printed circuit board (PCB).
- LCC Image Sensors require longer soldering times for RoHS high temperature solders.
- The ceramic substrate “expands” while the solder joint is “fixed” and cracks.
Key Benefits for Andon Electronics patented LCC Sockets:
- Avoid color array high temperature soldering damage.
- Avoid electrostatic discharge (ESD) production line problems.
- Avoid cleaning solutions clouding glass cover.
Reduce handling and ESD. Reduce Cost of PCB assembly for contract assemblers. Protect Sensors and color array from soldering temperatures and cleaning solution damage.
*US Pat #5,588,847
