Ironwood Electronics’ new Spring Pin sockets (ESS) can be easily customized for specific test height, force, plating finish, materials, etc. The spring pin functions as the interface between the IC package and the circuit board. These contacts support up to 34GHz bandwidth with standard designs, and with customization, impedance can be matched for highest electrical […]
High Performance Near Zero Footprint Sockets for 0.25 + pitch devices for Both BGA and lead and leadless packages. New Configuration using the proven GT elastomeric contact element allowing 43 Ghz Bandwidth (Measured on 0.5 pitch BGA -S21 @-1dB @ 43 GHz) 1000+ insertions on the same device with many lid options. Ironwood Electronics new […]
Heat-sink is for 23x23mm BGA 1mm pitch socket using GT contact that has 30g force per ball, provide >94 GHz signal speed, cycle life up to 2000 insertions, and operated at -55°C to +160°C.
Socket and test 24x24mm BGA with 1.27mm pitch using stamped spring pin contact that has 19g force per ball, cycle life of 125000 insertions and operates at -55°C to +180°C.
Ironwood Electronics offers high performance test sockets and adapters for both engineering and production use of semiconductor devices. IC packages covered include QFN, BGA, SOIC, QFP, LGA, WLCSP and other SMT packages. Our GHz line of sockets with 6 different contact technologies supports up to 110 GHz bandwidth, >=0.2mm pitch, <=10000 pins, 500K insertions and […]
GHz elastomer, spring pin and other socket technologies can accommodate different lid options depending upon the application requirement. Typical choices are swivel-lid, clam-shell, double-latch, integral heat-sink, etc. Custom lid solutions are also available. Swivel Lid Heatsink Compression Screw Clam Shell Lid with Compression Screw […]
Shortest spring pin, 1mm compressed height, provides highest electrical bandwidth 60GHz with lowest inductance of 0.17nH along with 2A continuous current carrying capacity. Quarter turn spring loaded lid allows gradual pressure to CSP with easy chip replacement functionality.
KEL Corporation has developed the 2.1mm pitch crimp connector “FK series” 2.1mm pitch crimp connector “FK series” Left side of photo: 5 poles Right side of photo: 7 poles <Product overview> – 2.1mm pitch crimp connector ideal for applications such as manipulators, robots, and mounters. ※For more information please refer to the <Application> section !! […]
Brightening Connections: The Advantages of Colorful Connectors The choice of connector color, often overlooked, holds significant value in practical applications, from simplifying installations to facilitating quick maintenance checks. Let’s explore how connectors with different color options can be not only useful but also add a touch of innovation to your projects. Why Color Matters The […]
New and Improved: SP/SY Cable Socket-C We’re thrilled to unveil a significant upgrade to our signature SP and SY series cable connector sockets. In our continuous pursuit of excellence and innovation, we’ve eliminated the gap between the connector’s main socket body and the back shell. This improvement: Strengthen the seal Boost the overall reliability and durability […]
