CBx-L1xxCSF Circular B-Size Male Connector, Male Pin, Front Mount, Lock Type, Round Flange, Solder Bucket Pin – Holin

CBx-L1xxCSF

Circular B-Size Male Connector, Male Pin, Front Mount, Lock Type, Round Flange, Solder Bucket Pin

Features:

  • Current rating: 2 / 5 / 10A
  • Waterproof rating: IP66-68
  • Temperature Range: -40°C to +105°C
  • Durability: > 1000 cycles
  • Nr. of Pin A-Coding: 2, 3, 4, 5, 6, 7, 8, 10, 12

Model PN.s: CBP-L102CSF, CBP-L103CSF, CBP-L104CSF, CBD-L102CSF, CBD-L103CSF, CBD-L104CSF, CBD-L105CSF, CBD-L106CSF, CBD-L107CSF, CBD-L108CSF, CBN-L110CSF, CBN-L112CSF

CBx-L1xxCSF
