CR 2032 V3 Lithium-Manganese Dioxide Coin Cells MnO2/Li 240 mAh

SPECIFICATIONS:

• Nominal Voltage: 3V
• Nominal Capacity: 240 mAh
• Standard Load: 15 kΩ
• Standard Current: 0.2 mA
• Max. Continuos Current: 3 mA
• Max. Pulse Current: 15 mA
• Operating Temperature: -30°C to +70°C
• Dimensions: Ø 22.00 +/- 0.15 x 3.60 +/- 0.2
• Weight Approx.: 3.5 gr.
• Chemistry: Li/MnO2
• UI1642: MH62838
• Termination Style: Solder Tab

CR 2032 V3
