CR 2450 V3 Lithium-Manganese Dioxide Coin Cells MnO2/Li 610 mAh · Jauch Battery

CR 2450 V3 Lithium-Manganese Dioxide Coin Cells MnO2/Li 610 mAh

SPECIFICATIONS:

  • Nominal Voltage: 3V
  • Nominal Capacity: 610 mAh
  • Standard Load: 7.5 kΩ
  • Standard Current: 0.4 mA
  • Max. Continuos Current: 4 mA
  • Max. Pulse Current: 15 mA
  • Operating Temperature: -30°C to +70°C
  • Dimensions: Ø 22.00 +/- 0.15 x 3.60 +/- 0.2
  • Weight Approx.: 7 gr.
  • Chemistry: Li/MnO2
  • UI1642: MH62838
  • Termination Style: Solder Tab

CR 2450 V3
