HC49/U-SMC Quartz Crystal

– SMD Crystal Version · 17.5 x 10.8 mm
– high frequency stability
– reflow soldering temperature: 260 °C max.
– customized versions available

• frequency range: 1.8432 ~ 40.0 MHz (fund. AT-cut) / 20.0 ~ 105.0 MHz (3rd OT AT-cut) / 50.0 ~ 175.0 MHz (5th OT AT-cut) / 70.0 ~ 250.0 MHz (7th OT AT-cut)

Quartz Crystal · HC49/U-SMC
