MQ1 (UM-1) Quartz Crystal

– Pin Type Crystal, 7.9 x 3.3 mm
– high frequency stability
– wave soldering temperature: 260 °C max.
– package height 8.0 mm max.

• frequency range: 0.9216 / 1.0 MHz*(fund. SL-cut) / 4.00 ~ 40.0 MHz (fund. AT-cut) / 20.0 ~ 105.0 MHz (3rd OT AT-cut) / 50.0 ~ 175.0 MHz (5th OT AT-cut) / 70.0 ~ 250.0 MHz (7th OT AT-cut)

Quartz Crystal · MQ1 (UM-1)
