SMU4 SMD Quartz Crystal · Jauch
SMU4 SMD Quartz Crystal
– 2 pad version, 11.5 x 4.8 mm
– low cost SMD type
– reflow soldering temperature: 260 °C max.
– package height 4.0 mm max.
- frequency range: 3.27680 ~ 33.0 MHz (> 33.0 MHz, ask if available)
